Type: Analogue

- Channels: 6 + 2
- EQ: Channel 1-4, 4-Band EQ / Channel A-B, 3-Band Parametric EQ
- USB Soundcards: Dual 24 Channel (12 in / 12 out) / Hi-Speed USB2.0 / Mac Class Compliant /32bit / 96kHz / MIDI over USB
- Line Inputs: 4 x RCA (CH 1-4) / 4 x 1/4″ TRS (CH A-D) Mono/Stereo
- Phono Inputs: 4 x RCA (CH 1-4) / LN/PH Switch for DVS
- USB Inputs: 6 x USB (CH 1-4 + CH A – CH B)
- Mic Input: 2 x XLR
- Master Output: 1 x XLR (Balanced)
- Master 2 Output: 1 x 1/4″ TRS (Balanced)
- Booth Output: 1 x 1/4″ TRS (Balanced)
- Record Output: 1 x RCA (Un-balanced)
- Master Insert: 1 x 1/4″ TRS
- MIDI Out: 1 x 5-Pin DIN
- Send/Return I/O: 2 x 1/4″ TRS Send / 4 x 1/4″ TRS Return / 1 x LN/Hi-Z Switch (SND1/RTNA)
- Filter: 2 x VCF Filter / HPF / BPF / LPF / Adjustable Frequency & Resonance / Assignable CH 1-4 + CH A-B / CRUNCH (Controlled Harmonic Signal Distortion)

- X-Link: 1 x RJ45
- Headphones: 2 x 1/4″ / 2 x 3.5mm / Split Cue Monitoring
- Channel Faders: 60mm VCA / Replaceable
- Chanel Meters: 9 Segment LED
- Channel Fader: Curve 3 Types
- X-Fader: InnoFADER / 45mm VCA / Replaceable
- X-Fader: Curve 3 Types
- Earth Ground Terminals: x 2
- Headroom: 20dB
- AC Mains: 100 to 240V / AC 50/60Hz / Consumption 45W max
- Mains Adaptor: 3 pin IEC socket
- Height: 109mm / 4.3″
- Width: 336mm / 13.25″
- Depth: 410mm / 16.2″
- Weight: 7kg / 15.4 lbs.


INCLUYE PROTECTOR POLVO UDG
